Name:

Iso10816_01 to Iso10816_04

名称:

Iso10816_01 to Iso10816_04



Registers for reading the RMS value (per ISO 10816) of the respective channel.

Iso10816 is formed from the raw signal of the oscillation velocity in a frequency range from 10 Hz to 1 kHz.

This broad characteristic value is often used in the assessment of the machine condition since assessment limits are specified for this characteristic value in the standard. These depend on the type of machine and type of installation (rigid or elastic). The characteristic value limits for a pre-warning or a warning are given according to their defined classification.



用于读取相应通道的有效值（根据 ISO 10816 ）的寄存器。

Iso10816 是由频率范围在 10Hz 到 1kHz 的振荡速度的原始信号形成的。

这个广泛的特征值通常用于机器状况的评估，因为标准中为此特征值规定了评估限值。这些取决于机器类型和安装类型（刚性或弹性）。预警或警告的特征值限值根据其定义的分类给出。



Fig.: ISO assessment scheme

图.: ISO 评估方案



If the machine condition is in order, this characteristic value is low. If damage occurs, then this value increases severely. If the RMS is assessed in the range of the oscillation velocity, lower frequency portions such as drive speed (and associated imbalance and/or misalignment) that are emphasized more and reflected more heavily in the characteristic value.



如果机器状况正常，这个特征值就很低；如果发生损坏，那么这个值就会严重增加。如果在振荡速度的范围内评估有效值，低频部分，如驱动速度（以及相关的不平衡和/或不对中）会更明显，并在特征值中反映的更多。



Characteristic value in Function model 0 - Standard

在 Function model 0 - Standard 功能模型的特征值



Characteristic value in all other function models

其它功能模型中的特征值
