X20CM4800X - Data sheet V1.04
The reference moment on the POWERLINK network is always calculated at the start of cycle (SoC) of the POWERLINK network. The SoC starts 20 µs after the system tick. This results in the following difference between the system time and the POWERLINK reference time:
POWERLINK reference time = System time - POWERLINK cycle time + 20 µs.
In the example above, this means a difference of 1980 µs, i.e. if the system time and POWERLINK reference moment are compared at time 25000 in the task, then the system time returns the value 25000 and the POWERLINK reference moment returns the value 23020.
